The Works compromise of managing crane for the pre-construction condition on defined private properties which may be impacted by construction works of the project

The Scope of Works includes the identification, testing, safe handling, and removal of naturally occurring asbestos present across the project alignment in accordance with Project Technical Specifications and Legislation. The subcontractor shall provide, but not limited to, all management, supervision, transportation, plant, equipment, materials, and personnel necessary to complete the works.

TBA

Plant Hire and Equipment - Wet and Dry Hire. Please refer to CWO-T-CIV.020.1 and CWO-T-CIV.020.2. As this package was split due to size of it.

The scope includes supply and delivery of equipment and conductor steelwork support structures transmission line lattice towers and monopoles. It includes, but is not limited Preparation of general arrangement and shop drawings and associated bill of materials (angles, plates and bolts) based on the indicative steel tower support structure outline drawings supplied by the Head Contractor)

Design cost and program coordinator

The Subcontractor will be required to provide Temporary Works Design and certification for any necessary works on site. This includes, but is not limited to, the provision of all necessary vehicles, plant, equipment, materials, goods, items, tools, and services for personnel, safety and protective clothing, consumables to execute the works.

The Base Scope of Works comprises of the design, testing, manufacture, and supply of Various conductors and delivered to Sydney Port, Australia (CIF incoterms). The Works must also include all necessary effort from the Supplier to guarantee warranty of the conductors. All Supplier's Activities must be undertaken in accordance with this Scope of Works and the Technical Specification provided.

The scope of work includes fencing on the site for the Central West Orana Project.

The supply and delivery of construction related signage including site naming, wayfinding signage, construction signs.

The supply and delivery of drainage materials for water crossings, including, but not limited to: concrete and HDPE pipes, and fittings; headwalls; culverts etc.. This package will primary function on a schedule of rates.

The supply and delivery of rural materials including, but not limited to rural fencing, electric livestock fencing and rural fencing gates

The subcontract comprises of the engagement of a Subcontractor to assist in the coordination and supply of appropriately qualified temporary labour personnel as required for project delivery. This includes, but is not limited to, the provision of all necessary vehicles, plant, equipment, materials, goods, items, tools, and services for personnel, safety and protective clothing, consumables to execute the works.

The works in this package comprises of the supply, delivery, and installation of Temporary Fencing to the Central-West Orana Project. This package will primarily function on a schedule of rates. The Supplier shall provide all management, supervision, transport, handling, and is responsible for the appropriate and safe unloading methods of material.

The Scope of Works comprises of undertaking stabilisation works to in-situ ground including all labour, plant, equipment, and materials. The Subcontractor shall make allowance for the supply and install of stabilisation material to the affected areas as nominated by the Head Contractor.

The Subcontractor will be required to supply, maintain, operate the mobile plant required for a crushing and screening operation required on the Central-West Orana Project. This package will primarily function on a schedule of rates, however the Subcontractor is not limited to the schedule of rates, as they must adhere to other aspects of the contract such as the projects EH&S procedures.

The Base Scope of Work comprises of the design, manufacturing, testing and supply of 500kV, 330kV and 33kV Protection Relays to a port in New South Wales, Australia (CIF incoterms). The Works must also include all necessary effort from the Supplier to guarantee Warranty of the equipment to be installed by the Head Contractor.

The Scope of Works includes the supply and installation of significant lengths of rural fencing and gates across the project alignment in accordance with the Environmental Impact Statement and Project Technical Specifications. The subcontractor shall provide, but not limited to, all management, supervision, transportation, plant, equipment, materials, and personnel necessary to complete the works.

Supply & Delivery only to site. 50mm to 150mm Orange & 50 to 100mm White.

The Subcontractor will be required to provide Temporary Works Design for traffic staging and certification for any necessary works on site. This includes, but is not limited to, the provision of all necessary vehicles, plant, equipment, materials, goods, items, tools, and services for personnel, safety and protective clothing, consumables to execute the works.

This scope of work include the demolition of existing private structures/residences. Works will require the removal and suitable disposal of all excess material.

This scope of works relate to the transmission tower bored pile foundation. Pile diameter ranges from 900mm to 2500mm, depth between 5-20m deep, approx 3000 quantity in total across all 10 separable portions of the project (27,000m3 excavation, 28,500m3 concrete, 2250T steel). The primarily works are drilling of piles using piling rigs, install pile reinforcement cages and pour concrete to the the cut off level. Based on the ground conditions, installation of permanent casings may be required to prevent soil from collapsing. There is also a requirement to install temporary casing to bring pile to the correct level for stub installation. The works must also include the installation of the transmission tower stub, which is setup prior to the pour. The purpose of the stub is to facilitate the erection of the transmission tower afterwards. Jig templates used to hold the stubs may also be procured by the contractor.

This Scope of works relate to the construction of access and driveways of all entry points at Merotherie Road, Birkalla Road, Blue Springs Road, Highett Road, Cope Road, Main Street, Ulan Road, Ulan-Wollar Rd, Entrance to Moolarben, Wilpinjong Road, Wollar Road, Upper Cumbo Road, Barigan Road, Dapper Road, Upper Laheys Creek, Spir Road, Tucklan Road, Castlereagh Highway, Gingers Lane, Barneys Reef Road, Whistons Lane, Puggon Road, Cliffdale Road, Turill-Uarbry Road (Turill Bus Route), Summer Hill Road, Golden Highway, Coolah Road, Rotherwood Road, Moorfield Road, Birriwa Bus Route South as well as the construction of typical Site Access Gates required on the Central-West Orana Project

The Base Scope of Work comprises of the design, manufacturing, testing and supply of 500kV, 330kV and 33kV Busbars Equipment to a port in New South Wales, Australia (CIF incoterms). The Works must also include all necessary effort from the Supplier to guarantee Warranty of the Equipment to be installed by the Head Contractor.

This scope of work includes the truck hire of providing maintained trucks of various sizes to meet the transportation requirements of the project. All vehicles and their movements will be required to occur in accordance with the overarching transport requirements of the project and work to head contractor instruction.

The Subcontractor will be required to complete the Early Work Pavement on the Central-West Orana Project. The Subcontractor will be required to supply, maintain, operate, and manage all resources to deliver the scope in accordance with the Head Contractor's project requirements. - Summary of works: - Spray Sealing - Asphalt - Linemarking (roadway and Carpark)

The Works comprise the undertaking of traffic control for the project to be carried out to industry best practice, the relevant Council standards, and TfNSW G10 Traffic Management including the provision of workers who are adequately licensed, ticketed, and competent to perform traffic control works.

Supply & Install permanent fencing and security gates for substations. * Please note this package will be released as multiple packages due to the geographical location and different timeline of the projects.

This scope of works is for the supply and delivery of precast elements for The Laheys Creek Bridge and Merotherie Road Bridge. The precast elements for each bridge is as follow: 10 PSC Planks (700mm deep, 22620mm long) for Merotherie Road Bridge. 14 PSC Planks (1100 deep, 26450mm long) for Laheys Creek Bridge. Precast parapets for Merotherie Road bridge (parapets are required for one span only, number and dimensions of parapets TBC). Precast parapets for Laheys Creek Bridge (parapets are required for one span only, number and dimensions of parapets TBC).

Supply & Install permanent fencing and security gates for substations. * Please note this package will be released as multiple packages due to the geographical location and different timeline of the projects.

The project involves the manufacturing of prefabricated amenities buildings, including the design, supply, and factory acceptance testing of air-conditioning, ventilation systems, lighting, power, and fire services, along with the installation of alarm systems. The buildings will consist of lunchrooms, offices, ablution rooms, and furnished spaces

ACE REZ is seeking a quote to complete all Road safety tasks related to the Project. Please note this scope covers the review of all road safety related tasks required for planning purposes. The pre-construction/ construction related tasks are to be covered in a subsequent tender package.

The Base Scope of Works comprises of the design, manufacturee, testings and supply of:22/33kV 3MVA Dyn11 Auxiliary Transformer, inclusive of a 22kV RMU per transformer, 22/0.4kV 500kVA Dyn11 Auxiliary Transformers, 33/0.4kV 500kVA Dyn11 Auxiliary Transformer, 33/0.4kV 500kVA ZNyn11 Earthing Transformer, All Auxiliary and Earthing Transformers shall be shipped to Port Botany in Sydney, New South Wales, Australia (CIF incoterms).

The Scope of Works comprises of quarry material supply to the Central-West Orana Project. This package will function on a Schedule of Rates, however the Subcontractor is not limited to the schedule of rates, as they must adhere to other aspects of the contract such as the projects EH&S procedures.

This scope of works relate to the supply of precast reinforced concrete box culverts and reinforced concrete pipes and headwalls in accordance with Project's specification in particular RMS Specifications R11, R16 and B80

The Scope of Works includes the supply and installation of complex water crossing across the project alignment in accordance with the Environmental Impact Statement and Project Technical Specifications. These works are including, but not limited to, the installation of large culverts, headwalls, and pipes, in substantial bodies of water. The subcontractor shall provide, but not limited to, all management, supervision, transportation, plant, equipment, materials, and personnel necessary to complete the works. The subcontractor shall be local to the area and have an understanding of the land and waterways.

This scope of works relate to the transmission tower pad footing foundation. The Subcontractor will be required to excavate down to top of rock level, drill 200mm passive anchors, grout and install 40mm tensile bars x 5m long. The subcontractor will then need to perform steel fixing for the pads and concrete pour. There is also a requirement to install the stub to the right position' for the transmission towers prior to the concrete pour. The purpose of the stub is to facilitate the erection of the transmission tower afterwards. Verification of the stub will be done by the Head Contractor once stub is installed.

The Base Scope of work comprises of the design, manufacture and delivery of various outdoor Low Voltage Marshalling Panels, outdoor Main Switchboards, outdoor AC and DC Distribution Boards and passively-cooled double-skinned outdoor Equipment Kiosks for active equipment. Conceptual layout and wiring schematics will be provided. The Design scope comprises development of shop drawings based on the provided concepts, thermal modelling, arc flash studies and all relevant design calculations as required.

The supply and delivery of floor mats (bog mats) with a capacity of up to 30 tons for the storage and assembly of transmission tower parts. Estimated quantities will be sent along with the scope of work, but this package will operate primarily on a schedule of rates and the supplier must be able to provide separate deliveries as required by the contractor

Logistics services for the transportation of materials and equipment from port to designated delivery points for the CWO project. It includes site establishment, biosecurity measures, compliance with heavy vehicle regulations, port clearance costs, container collection and destuffing (20ft and 40ft containers), holding charges for temporary equipment storage, and designated delivery routes. We are seeking proposals from logistics contractors capable of managing these operations efficiently.

The Base Scope of Works comprises of the design, testing, manufacture, and supply of Various conductors and delivered to Sydney Port, Australia (CIF incoterms). The Works must also include all necessary effort from the Supplier to guarantee warranty of the conductors. All Supplier's Activities must be undertaken in accordance with this Scope of Works and the Technical Specification provided.

This scope relates to Non-Destructive digging. The subcontract must perform non-destructive digging, identify the services, the depth, location/depth accordance with the project STR.

The supplier will be required to design, supply and deliver all construction related signage to the CWO REZ project. General construction signage will include, but not limited to, health and safety, site and gate information, and directional signs. Additionally, transmission line tower wayfinding and numbering signage is to be developed and provided. All signage must be customisable to meet ACEREZ and our clients branding guidelines, as well as meet project and applicable legislastive standards

Subcontractor to install only, 50mm to 150mm conduit in ground, inclusive of miscellaneous material, such as pvc glue and marker tape. Excavation, and backfill will be completed by others

The Work comprise the CCTV survey, cleaning and repairing of the installed drainage on the project in accordance with the project specifications, design drawings and best industry practice. The requirements includes but not limit to: Close circuit television (CCTV) surveys of drainage pipelines in accordance with WSAA Conduit Inspection Reporting Code (WSA 05-2013-3.1); installation of CCTV to include horizontal / vertical survey or electronic detection undertaken to obtain asset level information; Review and Assessment of CCTV survey required to determine and provide reporting; Provide a record of all recorded information from survey ;and etc.

The work under the scope includes the supply, assembly, installation/stripping of formwork, reinforcement fixing and the pouring of all in-situ concrete (FRP - form, reo, pour). The FRP is required for the following structures: Merotherie Road Bridge Laheys Creek Bridge

The Subcontractor will be required to complete the line marking and line marking removal for road upgrades, new camps roads, road access gates and Highway intersections upgrades The line marking will be required for the following locations: Merotherie Road upgrade Spring Ridge Road upgrade Neeleys Lane Camp internal roads Merotherie Camp internal roads Access gates for approved transportation routes (currently there are 93 gates that will be, but this is subject to change) Highway intersections upgrade (10 intersections will be updated) Line marking removal will be mainly required on the highway and several of the access gates roads This package will primarily function on a schedule of rates, however the Subcontractor is not limited to the schedule of rates, as they must adhere to other aspects of the contract such as the projects EH&S procedures.

Scope of work is divided in multiple separable portions. The subcontractor will be required to supply and apply spray seal on all the road upgrades, new camps roads, road access gates and highway intersection upgrade. Subcontractor is responsible for providing all labour, plant, equipment and materials and material storage and handling. Head contractor will be responsible for providing a list of works which may include multiple access gates as one work location and head contractor can Subcontractor is responsible for the Supply and application of the following types of spayed bituminous surfacing as required under the designs and standards: . Prime . Prime seal . Seal or reseal . Precoating Aggregate . Application of Precoating Aggregate . Curing membrane application . Removal of loose aggregate

This project involves two bridge structures: Merotherie Road Bridge and Laheys Creek. Each bridge is one span bridge with two abutments, with a total of six piles per bridge. The pile dimensions and spacing differ between the two bridges. For the Merotherie Road Bridge, the pile diameter is 1200mm, and length between 9725mm to 11430mm. For the Laheys Creek Bridge, the pile diameter is 1050mm, with a length between 4700mm to 5000mm. The scope of work for the pile installation includes drill and install bore piles with the inclusion of casing to support the bridge structure. As per the design, piles to be bored to a depth as defined in the design or to a specified bearing stratum.

This scope of services is focused on the supply of ice machines for 1200 workers at the Merotherie camp site during the delivery period.

This scope of work relates to small and large foundations for structures and porticos as well as fire walls, power transformers, control rooms, buildings etc. The subcontractor will be required to excavate in accordance with the engineering drawings and execute the foundations with rebar and threaded bolts aligned and levelled. The subcontractor will then be required to carry out the steel fixing for the slabs and the concrete pouring. There is also a requirement to install the formwork for the concrete pouring. The installation of conduits for electricity and drainage is also a scope of this package as well as the slabs for the general fences and gates.

Provision of routine and emergency repairs, facility upkeep, and management of maintenance requests for 1200-person camp. This encompasses maintaining all camp facilities and equipment per the Asset Register, ensuring compliance with safety standards, and coordinating with Camp Manager for specialised services.

The Base Scope of Work comprises of the design, manufacturing, testing and supply of 500kV, 330kV and 33kV Equipment to a port in New South Wales, Australia (CIF incoterms). The Works must also include all necessary effort from the Supplier to guarantee Warranty of the Equipment to be installed by the Head Contractor.

The scope of activities shall be design, build, and install of 100m X 80m X 12m temporary warehouse with 2 gates (truck access), and 2 access man door. The building must have a 20m x 20m area temperature and humidity controlled, should have stormwater and plumbing system, electrical fittings, complete fit out of offices for 50 people, access for disabled people & washrooms. Two 20m x 20m will be considered inside the warehouse and defined in design stage to store Oil tanks and gas tanks. Important Note: Standard fire protection requirements should be implemented meeting all relevant Australian Standards.

As part of the Central west Orana Rez Project, we are seeking expression of interest ( EOI) from potential vendors to design, supply, FAT and Type Test, building fit-out (at building supplier's factory), delivery, and installation of Equipment at 15 locations( Substations and maintenance facility) , commissioning and handover of the CCTV and Security Equipment inclusive of Warranty.Vendor must provide: CCTV and security equipment as specified, Install CCTV and security equipment in the buildings located at the building supplier's facility. FAT and Type testing of the CCTV and security Equipment, Supply of operation and maintenance manual. Guarantee and warranty of the equipment. Assistant head contractor with secondary and software integration with the security system.

The contractor's objective is to design, supply, install, and commission a Solar PV system integrated with a Battery Energy Storage System (BESS) and a generator power supply, providing a comprehensive turnkey solution for the Merotherie Camp site, based on the project load requirements.This solution must accommodate the specified loads, considering peak load times. The deliverables include single line diagrams, MSB shop drawings, PV mounting structures, and details on the type and manufacturer of equipment. The project Camp load will be in the vicinity of 5,000 amps.

We are seeking EOIs from experienced contractors for the preassembly and erection of structural steel and prefabricated components for the CWO-REZ project in NSW. The scope includes handling, bolting, lifting, alignment, and minor field welding of gantries, towers, and steel frames, in full compliance with safety and quality standards. Contractors must provide all lifting gear, skilled and qualified labour, rigging plans, and temporary supports, and coordinate closely with foundation, logistics, and electrical teams.

Pre-fabrication of the foundation cages by reviewing designs, sourcing materials, assembling, and inspecting the cages, then storing and transporting them to the construction site. * Please note this package will be released as multiple packages due to the geographical location and different timeline of the projects

The Supplier will be required to supply, delivery, install, commission, maintain and de-commission the Generators for use in the camp accommodation for Central-West Orana Project. The main Project accommodation village will be a 1200 bed facility located at Merotherie. Second accommodation village with 300 beds will be situated at Neeleys Lane.

This scope of services encompasses the supply, delivery, installation, commissioning, and training for compactor bins, including all necessary equipment. The bins will be delivered and installed at key construction site locations during the specified delivery period from March 2025 to January 2029. The primary locations for installation will be Merotherie Energy Hub, Elong Elong Energy Hub, Barrigan Creek Energy Hub, and Neelys Lane campsite. The bins are to be placed at the designated locations during the delivery phase to support waste management needs across these sites.

The scope of works for site security includes the provision of security personnel, systems, and monitoring to safeguard the Merotherie Village, energy hubs, and associated facilities. The Subcontractor will supply trained security guards to patrol key areas, control access, monitor CCTV and alarm systems, and ensure the safety of equipment and personnel.

The Subcontractor will be required to complete the Early Works Utility Supply & Install on the Central-West Orana Project. The Subcontractor will be required to supply, maintain, operate, and manage all resources to deliver the scope in accordance with the Head Contractor's project requirements. . Summary of works: -Full supply, installation and commissioning of the electrical, communication and hydraulic works.

The works in this package comprises of the supply and delivery of Geotextile material to the Central-West Orana Project. This package will primarily function on a schedule of rates. The Supplier shall provide all management, supervision, transport, handling, and is responsible for the appropriate and safe unloading methods of material.

The Scope of this package is to supply Dual cab 4x4 vehicles (mining specification), 12-seat van 2x4, a Coaster Bus or similar 2x4. Supply options considered as part of this package include Outright Purchase, Operating Lease, and Rental/ Hire.

This package encompasses a comprehensive range of medical services aimed at promoting and maintaining employee health and wellbeing throughout their employment lifecycle.The scope includes pre-employment medicals, ongoing health surveillance programs, proactive wellbeing initiatives (flu shots, hydration checks, skin cancer checks, educational programs, etc), and the provision of qualified and experienced medical professionals to ensure comprehensive medical coverage and support for work-related injuries and emergencies during the different stages of the project.This comprehensive approach aims to proactively manage workforce health, prevent injuries, and maintain a safe and productive work environment throughout all phases of the project.

We are seeking an EOI from bus transportation companies for the provision of bus services to transport workers to Merotherie Camp located in Central West NSW (about 60km north of Mudgee). The service is required 7 days per week to and from Sydney. The frequency to other locations to be confirmed. Proposed pick-up locations are: . Sydney Central . Newcastle . Wollongong . Penrith . Regional towns - TBA

This scope is for the supply of robust caravans suitable for use by construction personnel for lunchroom and offices. Options for both purchase and rental will be considered.

The supply and delivery of common lifting equipment and accessories, including but not limited to: Slings, pulleys, chain hoists, shackles, etc. Various tools and materials will be required throughout the duration of the project, keeping a minimum quantity of the contractor's stock at all times. Estimated quantities will be sent along with the scope of work, but this package will primarily function on a schedule of rates.

As part of the CWO Rez Project, head contractor is inviting expression of interest from suitable Subcontractor to deliver the scope of direct buried fibre deployment in the transmission line easement. Subcontractor will be required to install around 120 kilometres of direct buried underground 96 fibre cables on different directions along eight (8) separable portions (SP). The route for the cables will follow the clearance boundary of the transmission lines directly under the conductors, with trenching being assumed as the primary method of construction, Horizontal directional drilling (HDD) may need to be used at the various road, rail and creek crossings if deemed necessary by project manager and relevant environmental or geotechnical personnel. The estimated length of drilling using the HDD method is 3.1 kilometres separated in various points of crossings. HDD under roads and creeks are to comply with relevant road and drilling standards. It shall be noted that the quantities are subject to changes as the project still undergoing Design phase.

The Subcontractor shall be responsible for undertaking any works required to existing Utilities located inside the Project construction boundary and will follow the treatment plan assigned to each Utility i.e., protect or relocate. The Subcontractor will be responsible for carrying out all tasks associated with the protection and relocation of electrical utilities, including the supply, delivery, and installation of utility conduits, pits, and other accessories, HV & LV cabling, and power poles. This will be carried out in full compliance with project specifications and the Utility Service Authority requirements. The Subcontractor must be accredited with ASP1 accreditation as per the NSW guidelines. The Subcontractor must be authorised by the Utility Service Authority as an accredited service provider at the appropriate level and class, including but not limited to Essential Energy. Furthermore, as part of the ICN submission, the Subcontractor must submit the list of the Utility Service Authority they are accredited with and authorized to work for.

Supply and delivery of flexible concrete box culverts for moderate water crossings along access routes for transmission lines. The supplier must provide all technical certificates for the culverts. It must be possible to split deliveries into different dates, according to the needs of the main contractor. Estimated quantities will be sent along with the scope of work, but this package will work mainly based on a schedule of rates.

The work in this package comprises the supply and delivery of earthing material for the foundations and fencing/gates to the Central-West Orana Project. Estimated quantities will be sent along with the scope of work, but this package will work mainly on the basis of a schedule of rates.

Supply and design of high-level fire rated Fuel Farm and all ancillary items Supply of a provin fuel dispensing and recording system, with a high-security rating.

Design, establishment, supply/hire, installation, and demobilisation of temporary site offices, amenities, and facilities

Rock breaking & removal for the Central West Orana transmission line project at various locations within the project boundary. Solutions include use of expansive mortar or low impact blasting. The subcontractor gives rates for both product supply and complete execution of services. The Supplier must send all the support documentation necessary to the Head Contractor. Along with the scope of work, estimated quantities of rock volume will be sent, this package will operate on a schedule of rates basis.
